Processing materials
Elastic or non-elastic mesh and plain fabrics
Applications
Swimwear, lingerie, stockings, tablecloths, curtains, decorative fabrics, apparel textiles, metal fabrics, etc.
Features
- High speed raschel warp knitting machine adopts an optimized crankshaft connecting rod transmission mechanism.
- Raschel warp knitting machine uses compound needles allows for knocking over from the bar, ensuring faster production speeds.
- The single needle bar raschel warp knitting machine allows for electronic yarn let-off (EBA), electronic fabric take-up and electronic batching.
Specifications
Needle type Compound needle
Gauge E16, E28, E32
Number of bars 2/4 bars
Working width 170"
Max. speed 2300 rpm
Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
GE2266-170" | 6500×2550×2950 | 16.95 | 10000 | 16.5 |
