Applications
Faux suede fabrics, eco-friendly air conditioning filter materials, and short, medium, and long plush jacquard fabrics used in apparel textiles, home textiles, filter screens, blankets, plush toys and home upholstery.
Features
- Faux suede fabric warp knitting machine uses an oil immersed cam-linkage mechanism and 3 fixed ground bars.
- Raschel warp knitting machine allows for complex jacquard.
- The textile machinery has functions of electronic yarn let-off and EL pattern drive with electronic guide bar drives.
- Finished plush products have minimal shedding.
Specifications
Needle type Individual latch needle, block latch needle
Gauge E16, E18, E22
Number of bars 8 bars
Distance between knocking-over bar 10-80mm
Working width 100"/110"
Max. speed 700 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 3700×6615×3750 | 24.4 | 8000 | 19 | |
| 4350×6615×3750 | 28.7 | 9350 | 20 |
