Applications
Regular jacquard plush fabrics
Features
- High speed warp knitting machine uses an oil immersed cam-linkage mechanism and a fixed knock-over comb bar.
- Raschel warp knitting machine adopts short latch needles for fast processing speed and fabric output.
- Raschel warp knitting machine has functions of electronic yarn let-off, electronic fabric take-up and electronic guide bar control (EL).
Specifications
Needle type Block latch needle
Gauge E22
Number of bars 4 ground bars, 4 pile bars
Distance between knocking-over bar 2-16mm
Working width 100"/138"
Max. speed 550 rpm
| Machine Model | Dimensions (L×W×H) | Floor Area (m²) | Machine Weight (kg) | Total Power (kW) |
| 4800×6050×3400 | 29.04 | 10000 | 20.5 | |
| 5500×6050×3400 | 33 | 12000 | 24 |
